Product family » School-light
Spotlight recessed into custom-made stainless steel handrail Wide choice of lenses:
- Very extensive asymmetric versions to ensure beam uniformity with intervals of up to 7m.
- Tilted beam to have tilted output even when the product is installed vertically to hide the light source.
APPLICATIONS:
- Handrails
- Cycle paths and pedestrian paths lighting
- Roadway lighting
-
Lighting
2 product(s) in lighting
5639 - School-light New
Application
-
Lighting
Outdoor lighting
- This value is gained from the optimum output of the LED number, inclusive of optic, for a cool white LED (6000K) Standard flux :259 lm
Mounting type
-
Wall recessed
-
Handrails
Features
-
Weight
160 gr
Options of luminous effects
-
20° deflected beam (option)
-
Non adjustable
-
Beam with various openings
-
Transparent flat window
Power supply - Control
-
Cable length
0.2m -
24V-PWM
Integrated24V-PWMRemote24V-0/10V,24V-DMX,24V-DALI
Material
-
Anodised glazed aluminium
-
Vandalism-proof, scratch-proof, UV-proof, polycarbonate window, M2
Mechanical strength - Waterproofness
Select your specific requirements with our product configurator, by filtering technical criteria. Download the configurated product datasheet.
-
Electricity consumption
-
Output
-
Maximum use temperature
-
Contact temperature
Product configurator
Optic options available for the product: 5639 School-light
Your search criteria :
Number of LEDs :
Type of LEDs :
Colour :
Select the tab of your choice and click on your chosen optic, then confirm.
Access the photometric data
Photometric data
Optic options available for the product: 5639 School-light
Your search criteria :
Number of LEDs :
Type of LEDs :
Colour :
Select the tab of your choice and click on one or more chosen optics, then confirm.
Technical data is subject to changes.
Luminaire guaranteed 5 years.
Luminaire designed and manufactured in France.
Luminaire guaranteed 5 years.
Luminaire designed and manufactured in France.
"Mini" version with 3 LEDs
- Colourless anodised machined aluminium
- Vandalproof organic glass window
- Flush-recessed
- 316L Stainless steel handrail available on request (Ø48mm or 76mm). Other sizes are available on a made-to-measure basis
- RGB options available
- Colourless anodised machined aluminium
- Vandalproof organic glass window
- Flush-recessed
- 316L Stainless steel handrail available on request (Ø48mm or 76mm). Other sizes are available on a made-to-measure basis
